10kW Power Wall LiFePO4 Battery

Payment Type:

L/C,T/T

Incoterm:

CFR,CIF,FOB

Min. Order:

1 Set/Sets

< >

Overview

Product Attributes

Brand: HAOXUAN

Supply Ability & Additional Information

Payment Type: L/C,T/T

Incoterm: CFR,CIF,FOB

Packaging & Delivery

10kw Power Wall Lifepo4 Battery

Product Attributes

Selling Units: Set/Sets | Package Type: Carton or Wooden Box

Module Type
LFP 10kWh/LV
Total Energy* 5kWh
Usable Energy(DC)* 9.2kWh
Nominal Dis-/Charge Power 4.6kW
Peak Power(Only Discharge) 10kWh for 3 seconds
Constant Current(Only Discharge) 100A
Voltage 48~56Vd.c
Nominal Voltage 51.2Vd.c
Nominal Current 100A
Max. Charge Voltage 59.2V±0.5V d.c
Weight 125kg
Dimension(mm) 585(645)*940(995)*205(225)mm
Safety CE UN38.3
Max.recommended DOD 90%
Operating Condition Indoor or outdoor
Operating Charge From 0~45℃
Temperature Discharge From -10~50℃
Humidity 4~100% (No condensed water)
Pollution Degree 3
Over Voltage Category II
Cooling Type Natural cooling
Case Material Metal + Plastic
IP Rating IP 65
Protective Class I
Max. Number of Parallel or Series 16
Warranty 10 years
Life Span >15 years
Communication CAN
Protection Mode Triple hardware protection
Battery Protection Over-current / Over-voltage / Short circuit / Under-voltage
Hazardous Material Classification 9
