20kWh LiFePO4 Battery Power Wall

Get Latest Price

Payment Type:

L/C,T/T

Incoterm:

FOB,CFR,CIF

Min. Order:

1 Set/Sets

Contact Now

Product Description

Product Attributes
Supply Ability & Additional Information
Packaging & Delivery

< >

Overview

Product Attributes

Brand: HAOXUAN

Supply Ability & Additional Information

Payment Type: L/C,T/T

Incoterm: FOB,CFR,CIF

Packaging & Delivery

Selling Units:: Set/Sets

20kwh Lifepo4 Battery Lithium Powerwall

Product Attributes

Model No.: LFP5KWH/10KWH
Brand: HAOXUAN
Battery Type: Lithium Ion, LiFePO4
Cycle Life: 6000 times
Voltage: 51.2V
Capacity: 5kwh/10kwh
Application: Solar Energy System
Waterproof Level: IP67
OEM/ODM: Acceptable

Supply Ability & Additional Information

Packaging: Carton or Wooden Box
Productivity: 1GWH/YEAR
Transportation: Ocean, Air, Land, Express
Place of Origin: CHINA
Supply Ability: 1000pcs/day
Certificate: ISO, TUV, CE
HS Code: 8507600090
Port: Ningbo, Shanghai, Guangzhou
Payment Type: L/C, T/T
Incoterm: FOB, CIF, EXW, CFR, DDP, DDU

Packaging & Delivery

Selling Units: Set/Sets

Package Type: Carton or Wooden Box

Our wall-mounted lithium batteries are divided into two types: 5KWH and 10KWH. The main material of the Lithium Battery is the Battery cell. The battery cell we use is A+ grade battery cell, which is the best.

Electrical Characteristics

Module Type	LFP 5kWh/LV	LFP 10kWh/LV
Total Energy*	5kWh	5kWh
Usable Energy(DC)*	Usable Energy(DC)*	9.2kWh
Nominal Dis-/Charge Power	3kW	4.6kW
Peak Power(Only Discharge)	7kWh for 3 seconds	10kWh for 3 seconds
Constant Current(Only Discharge)	100A	100A
Voltage	48~56Vd.c	48~56Vd.c
Nominal Voltage	51.2Vd.c	51.2Vd.c
Nominal Current	60A	100A
Max. Charge Voltage	59.2V±0.5V d.c	59.2V±0.5V d.c
Weight	65kg	125kg
Dimension(mm)	490(550)650(700)196(216)mm	585(645)940(995)205(225)mm
Safety	CE UN38.3	CE UN38.3
Max.recommended DOD	90%	90%
Operating Condition	Indoor or outdoor	Indoor or outdoor
Operating Charge	From 0~45℃	From 0~45℃
Temperature Discharge	From -10~50℃	From -10~50℃
Humidity	4~100% (No condensed water)	4~100% (No condensed water)
Pollution Degree	3	3
Over Voltage Category	II	II
Cooling Type	Natural cooling	Natural cooling
Case Material	Metal + Plastic	Metal + Plastic
IP Rating	IP 65	IP 65
Protective Class	I	I
Max. Number of Parallel or Series	16	16
Warranty	10 years	10 years
Life Span	>15 years	>15 years
Communication	CAN	CAN
Protection Mode	Triple hardware protection	Triple hardware protection
Battery Protection	Over-current/Over-voltage/Short circuit/ Under-voltage	Over-current/Over-voltage/Short circuit/ Under-voltage
Hazardous Material Classification	9	9
