HJT Solar Cell with 166mm Size
  • HJT Solar Cell with 166mm Size
  • HJT Solar Cell with 166mm Size
  • HJT Solar Cell with 166mm Size

HJT Solar Cell with 166mm Size

Payment Type:
L/C,T/T
Incoterm:
FOB,CFR,CIF
Min. Order:
1 Set/Sets
Transportation:
Ocean,Land,Air
Share:
  • Product Description
< >
Overview
Product Attributes

Brand: HAOXUAN

Supply Ability & Additional Information

Transportation: Ocean,Land,Air

Payment Type: L/C,T/T

Incoterm: FOB,CFR,CIF

Packaging & Delivery
Selling Units:
Set/Sets
Solar Module HJT 166mm Solar Cell

Product Attributes

  • Model No.: 480M6/HJT
  • Brand: HAOXUAN
  • Place Of Origin: China
  • Types Of: Half Cell, Bifacial, Double-Glass, All Black, Hjt
  • Connector: MC4 Compatible
  • Mechanical Load: Front Side Max. 5400Pa, Rear Side Max. 2400Pa
  • Output Cables: 4.0mm², 50cm (+), 50cm (-), length can be customized
  • Dimension: 2094x1038x30mm
  • Weight: 27kg
  • Solar Cells: HJT Mono crystalline 166X83mm (2x72pcs)
  • Front Glass: AR Coated 2mm+2mm tempered glass
  • Frame: Anodized aluminum
  • Junction Box: IP68, 3 bypass diodes

Supply Ability & Additional Information

  • Packaging: Carton/Wooden Box
  • Productivity: 2GW/YEAR
  • Transportation: Ocean, Air, Land
  • Place of Origin: CHINA
  • Supply Ability: 2000pcs/day
  • Certificate: ISO, TUV, CE, CQC, INMETRO, RETIE
  • HS Code: 8541430000
  • Port: Shanghai, Ningbo, Shenzhen
  • Payment Type: L/C, T/T
  • Incoterm: FOB, CIF, EXW

Packaging & Delivery

Selling Units: Watt/Watts
Package Type: Carton/Wooden Box

Haoxuan HJT PV Module 460-480M6

166mm 144cells

RAW MATERIALS

  • CELL BY TW
  • GLASS BY XINYI / SG
  • EVA BY FIRST/BBETTER
  • BACKSHEET BY JOLYWOOD
  • JUNCTION BOX BY QC
  • FRAME BY TENTOP

LABELS OEM OPTIONAL

20240419114132 Png

Electrical Characteristics (STC/NOCT)

Module Type 430M6 435M6 440M6 445M6 450M6 455M6 460M6
  STC NOCT STC NOCT STC NOCT STC
Maximum Power - Pmax(W) 430 317.4 435 321.1 440 324.9 445
Open Circuit Voltage - Voc(V) 48.5 45.3 48.7 45.5 48.9 45.7 49.1
Short- Circuit Current - Isc(A) 11.31 9.08 11.39 9.15 11.46 9.21 11.53
Voltage at Pmax - Vmp(V) 40.7 37.7 40.9 37.9 41.1 38.1 41.3
Current at Pmax - Imp(A) 10.57 8.42 10.64 8.47 10.71 8.53 10.78
Module Efficiency - ηm(%) 19.8 / 20.0 / 20.2 / 20.5
Power Tolerance(W) (0, +4.99W)
Maximum System Voltage(V) 1500Vdc (IEC / UL)
Maximum Series Fuse Rating (A) 20A

STC : Irradiance 1000W/m²，Cell Temperature 25℃，Air Mass 1.5

NOCT: Irradiance 800W/m²，Ambient Temperature 20℃，Air Mass 1.5， Wind Speed 1m/s

20240419114309 Png 20240419114317 Png

Key Features

  • 30 YEARS 90%+ OUTPUT
  • 22.1% ULTRA-HIGH EFF
  • 90%+ BIFACIALITY
  • -0.24%/℃ LOW TEMP COEFF
  • NO PID NO LID
